TIE ROD OUTER
The Tie Rod Outer is a Tie Rods and Sockets replacement part that fits 5 machines, including Fiat 1000, Fiat 1000 Super and Fiat 850. It cross-references OEM part numbers from Case-IH, CNH and Fiat (e.g. 5011757). Key dimensions: TA2 M16 x 1.5 - RH, Type V, Angle 270.
£22.99
exc. VAT
£27.59 inc. VAT
In Stock
Category
Steering > Steering Parts > Tie Rods and Sockets
Weight
1.77 kg
Dimensions (L×W×H)
52.5 x 16 x 17 cm
Fits: Fiat 1000, Fiat 1000 Super, Fiat 850, Fiat 900
Cross-references: 5011757 (Case-IH), SF5011757 (New Holland)
Compatible Vehicles & Equipment
| Type | Make | Model | Engine Make | Engine Model |
|---|---|---|---|---|
| Tractor | Fiat | 1000 | FPT - Iveco | 8065.02 |
| Tractor | Fiat | 1000 | FPT - Iveco | 8065.04 |
| Tractor | Fiat | 1000 Super | FPT - Iveco | 8065.04 |
| Tractor | Fiat | 850 | Someca | OM CO 3/80 |
| Tractor | Fiat | 900 | FPT - Iveco | 8065.01 |
Technical Specifications
Weight
1.77 kg
Dimensions
52.5 x 16 x 17 cm
TA2
M16 x 1.5 - RH
Type
V
Angle
270
D1 (mm)
18.3
D4 (mm)
20.0
H1 (mm)
93
H2 (mm)
80
Hole Ø
10
L1 (mm)
390
L2 (mm)
340
Number of holes
7
OEM Cross References
Case-IH
5011757
CNH
5011757
Fiat
5011757
New Holland
5011757
New Holland
SF5011757
Someca
SF5011757
