SWAGE NIPPLE METRIC 24° CONE S TYPE – FEMALE – 90° M24 X 1.5 – HOSE 1/2”

Name: SWAGE NIPPLE METRIC 24° CONE S TYPE – FEMALE – 90° M24 X 1.5 – HOSE 1/2”
Price: 7.19 GBP
Availability: InStock

SWAGE NIPPLE METRIC 24° CONE S TYPE - FEMALE - 90°

The Swage Nipple Metric 24° Cone S Type – Female – 90° M24 X 1.5 – Hose 1/2” is a replacement part for agricultural machinery. Key dimensions: Elbow 90°, A (mm) 66.5, B (mm) 22.

£5.99 exc. VAT

£7.19 inc. VAT

In Stock

Category 'TWO'' Piece Crimp Fittings > Metric

Weight 0.14 kg

Dimensions (L×W×H) 2 x 3.5 x 8 cm

Technical Specifications

Technical drawing for SWAGE NIPPLE METRIC 24° CONE S TYPE – FEMALE – 90°
M24 X 1.5 – HOSE 1/2”

Weight 0.14 kg

Dimensions 2 x 3.5 x 8 cm

Elbow 90°

A (mm) 66.5

B (mm) 22

D (mm) 16

Gender Femelle / Female

H (mm) 30

Hose Ø 1/2"

Tube (mm) 16

Designation DKOS-M24X1,5-45°-DN 12

Sort Thread Métrique / Metric

Thread / Ø M24 x 1.5

M24 X 1.5 - HOSE 1/2''
