BALL JOINT M22 x 1.5 RH – M22 x 1.5 RH
BALL JOINT
The BALL JOINT M22 x 1.5 RH – M22 x 1.5 RH is an Axial Rods replacement part that fits 10 machines, including Case-IH C55, Case-IH C64 and Case-IH CS48. It cross-references OEM part numbers from Case-IH, CNH and New Holland (e.g. 1-33-743-011). Key dimensions: TA1 M22 x 1.5 - RH, TA2 M22 x 1.5 RH, L1 (mm) 210.
Fits: Case-IH C55, Case-IH C64, Case-IH CS48, Case-IH CS52, Case-IH CS58, Case-IH CS63, Case-IH CS68, Case-IH CS75
Cross-references: 1-33-743-011 (Case-IH), 133743011 (Case-IH), 87718416 (Case-IH)
Compatible Vehicles & Equipment
| Type | Make | Model | Engine Make | Engine Model |
|---|---|---|---|---|
| Tractor | Case-IH | C55 | MWM | D226-B3 |
| Tractor | Case-IH | C64 | MWM | TD226-B3 |
| Tractor | Case-IH | CS48 | Perkins | 903-27 |
| Tractor | Case-IH | CS52 | Perkins | 903-27 |
| Tractor | Case-IH | CS58 | Perkins | 903-27T |
| Tractor | Case-IH | CS63 | Perkins | 903-27T |
| Tractor | Case-IH | CS68 | Sisu | 320D |
| Tractor | Case-IH | CS68 | MWM | TD226-B3 |
| Tractor | Case-IH | CS75 | MWM | TD226-B3 |
| Tractor | Case-IH | CS75 | Sisu | 320D |
Technical Specifications
OEM Cross References
1-33-743-011
1-33-743-011
1-33-743-011
133743011
133743011
133743011
87718416
87718416
87718416
87718416
